NAIT 50
Specificaties
Geluid
- Vervorming (THD + N): 0.015%
- Gain:
- Phono: +40dB (@1kHz RIAA)
- Preamp/headphone: +16dB
- Power Amp: +29dB
- Frequentierespons:
- Line: -3dB @ 4Hz t/m 45kHz
- Phono: -3dB @ 6Hz t/m 30kHz
- Stroomuitvoer:
- 25 Watt 8Ω @0,1% THD+N
- 40 Watt 4Ω @0,1% THD+N
- 60 Watt 2Ω @1% THD+N
- Signaal/ruisverhouding:
- Ref. 1 Watt 8Ω, A-weighted: Line: 80dB, 1V input / Phono: 78dB, 5mV input
- Ref. 25Watt 8Ω, A-weighted: Line: 93dB, 1V input / Phono: 84dB, 5mV input
- Headphone out: 1.5 Watt 16Ω
- Crosstalk:
- Line: 85dB, (1kHz, 25 Watt 8Ω)
- Phono: 80dB
Connectiviteit, Software & Integratie
- Invoer:
- 1 x RCA paar (47kΩ) in, MM phono level 5mV
- 2 x 5-pin DIN (stereo, 47kΩ), line level
Algemeen
- Typisch stroomverbruik: 20W
- Standby-stroomverbruik: <0,5W
- Voeding: 115V of 230V, 50/60Hz
- Afmetingen: 8.7×20.7×32.1cm
- Gewicht: 4,5kg (9,9lbs)
